Stator Formation
- 1.Punching of CRCA coil Strip
- 2.Hi-Perm of Loose Laminations
- 3.Stacking of Laminations
- 4.Copper Coils Making
- 5.Insertion of Winding in side stack slots
- 6.Forming of Wounded Stator
- 7.Lead Wire Connections
- 8.Taping and Lacing
- 9.Varnish and Backing
- 10.Surge Comparison Testing
ROTOR ASSY
- 1.Punching of CRCA coil Strip
- 2.Weighing and Skewing of rotor Laminations
- 3.Aluminum Die casting of Rotors
- 4.Sizing of Die casted Rotors
- 5.Reamering of Rotors
- 6.Lacquering of Rotors
- 7.Shaft Pressing Inside the Rotor
MOTOR ASSY
- 1.Surge Comparison Testing Of Stator
- 2.Attachment of Cover Assy and Rotor Assy
- 3.Fixing Of Nut-Bolts
- 4.On-Line Running Alignment of Motors
- 5.Motor Testing On Electronic Panel
- 6.Lead Crimping and Terminalising
PACKING
- 1.Name Plate Fixing over the Motor
- 2.Transparent Poly bag covering over the Motor
- 3.Insert Supports For Shaft and Base Plate
- 4.Motor Accommodation in side the Box
- 5.Taping and Sealing of the Box
- 6.Box Information Attachment on Box
- 7.Strip Wrapping and Locking of the Box
